iFi Audio ZEN Phono 3 | |
---|---|
Features: | |
Supports four MC/MM gain selections from 36dB to 72dB and four input impedance settings | |
Intelligent subsonic filter removes only the ultra-low frequencies caused by warps | |
EIN (Equivalent Input Noise) of -151dBV surpasses some Class A+ models by 20dBV | |
Precise RIAA with balanced output, performance matches that of a £1,000 phono stage | |
Internal high-tech 1.2MHz clean power supply, rivalling classic tube amplifiers' LC filtering circuits | |
Technical Specifications: | |
Input: RCA | |
Gain settings MC (v lo): 72dB (+/- 1dB) | |
Gain settings MC (lo): 60dB (+/- 1dB) | |
Gain settings MC (hi): 48dB (+/- 1dB) | |
Gain settings MM: 36dB (+/- 1dB) | |
Line Output: BAL 4.4mm/UnBAL RCA | |
Output Power (RMS): Balanced >19.98V @ 100kΩ (THD+N<1%); UnBAL >10.07V @ 100kΩ (THD+N<1%) | |
SNR: MM 91dB(A); MC High 71dB(A); MC Low 89.6dB(A); MC V Low 78.6dB(A) | |
Equivalent Input Noise: MM-127dBV(A); MC High -129dBV(A); MC Low -149.6dBV(A); MC V Low -150.6dBV(A) | |
Harmonic Distortion: MM < 0.0027% @ 600Ω; MC High < 0.0095% @ 600Ω; MC Low < 0.031% @ 600Ω; MC V Low < 0.022% @ 600Ω | |
Output Impedance: <200Ω BAL; <100Ω UnBAL | |
Frequency Response: 20-80kHz (-3dB) BAL; 20-20kHz (-0.15dB) UnBAL | |
Dimensions: 158x113x35mm (6.2” x 4.4” x 1.4”) | |
Weight: 456g (1.0 lbs) | |
