iFi Audio GO link Max | |
---|---|
Features: | |
Improved DAC setup - Dual ESS Sabre DAC chips form a balanced circuit | |
Balanced 4.4mm output, providing up to 241mW power | |
Dynamic Range Enhancement technology and THD compensation | |
Plug-and-play with USB-C ports | |
Hi-res audio: 32-bit/384kHz PCM and native DSD 256/11.3MHz | |
Silver-plated copper conductors, twisted for high signal purity | |
Gold-plated USB-C connector and headphone sockets | |
Flexible cable aids portability and reduces stress on USB sockets | |
Technical Specifications: | |
Input: USB-C | |
Hi-Res Audio Support: PCM 384kHz; DSD256 (11.3MHz) | |
DAC: Dual Bit-Perfect DSD & DXD DAC by ESS | |
Headphone Outputs: Balanced: 4.4mm / S-Balanced: 3.5mm | |
Output Power: Balanced (4.4mm) ≥241mW at 32Ω; ≥4V at 300Ω / S-Balanced (3.5mm) ≥100mW at 32Ω; ≥2V at 300Ω | |
Output Impedance: Balanced (4.4mm) <0.35Ω / S-Balanced (3.5mm): <0.7Ω | |
Signal-to-Noise Ratio (SNR): Balanced 130dB(A) at 600Ω (20Hz-20kHz) / S-Balanced: 125dB(A) at 600Ω (20Hz-20kHz) | |
Dynamic Range (DNR): Balanced 130dB(A) at 600Ω (20Hz-20kHz) / S-Balanced: 125dB(A) at 600Ω (20Hz-20kHz) | |
Total Harmonic Distortion + Noise (THD+N): Balanced ≤0.0016% at 2.4V (32Ω, 20Hz-20kHz) / S-Balanced: ≤0.0015% at 1.27V (32Ω, 20Hz-20kHz) | |
Frequency Response: 10Hz-80kHz (-3dB) | |
Power Consumption: No Signal ~0.6W / Max Signal: ~3.2W | |
Dimensions: 150mm (+10/-5) x 15mm x 10mm 5.9" (+0.4/-0.2) x 0.6" x 0.4") | |
Net Weight: 14.5g (0.51 oz) |
