Arcam SA10 Integrated Amplifier
Description
Description
Introducing the Arcam SA10 Amplifier: Redefining Audio Excellence
The highly anticipated successor to the award-winning A19 amplifier, the Arcam SA10 amplifier takes performance to new heights. This ultra-low distortion Class A/B amplifier outshines its predecessor, boasting unparalleled audio quality. Designed to raise the bar in digital audio, the SA-10 sets a new standard, delivering exceptional sound whether you're streaming music or playing it from CDs.
Immersive Soundstage and Precise Separation: Arcam SA10 Integrated Amplifier
Experience music like never before with the Arcam SA10 Integrated Amplifier. Meticulously crafted to offer a wide and deep musical soundstage, this amplifier ensures excellent stereo separation while minimizing interference. The incorporation of both a pre-amplifier and power amplifier enables seamless source switching, precise volume control, and superior amplification, capturing the smallest nuances of a performance.
Rediscover the Essence of Music with HDA Range
Revisit your favorite albums and uncover new dimensions in sound with the HDA range. Transform your listening experience with the Arcam SA10 amplifier, which reveals intricate details like a singer's breath before a chorus or a guitarist's fingers gliding over strings. Unlike ordinary Bluetooth speakers, the SA10 amplifies music with remarkable clarity and authenticity, bringing you closer to the artist's original intent. Whether it's a cherished classic or a long-forgotten recording, the HDA range offers a fresh perspective that will make you feel like you're hearing it for the very first time.
Key Features
Key Features
Specifications
Specifications
| SA10 Specifications | |
|---|---|
| Continuous power output (20Hz—20kHz at 0.5% THD), per channel |
|
| Both channels, 8Ω, 20Hz—20kHz | 50W |
| Single channel, 4Ω, at 1kHz | 90W |
| Harmonic distortion, 80% power, 8Ω at 1kHz | 0.003% |
| Analogue Inputs | |
| Phono (MM) cartridge | |
| Input sensitivity at 1kHz | 5mV |
| Input impedance | 47kΩ + 100pF |
| Frequency response (ref. RIAA curve) | 20Hz – 20kHz ± 1dB |
| Signal/Noise ratio (A-wtd) 50W, ref. 5mV input | 80dB |
| Overload margin, ref. 5mV at 1kHz | 21dB |
| Line Inputs | |
| Nominal Sensitivity | 1V |
| Input impedance | 10kΩ |
| Maximum input | 6Vrms |
| Frequency response | 20Hz – 20kHz ± 0.2dB |
| Signal/Noise ratio (A-wtd) 50W, ref. 1V input | 106dB |
| Digital Inputs | |
| DAC | ESS9016K2M |
| Frequency response | 20Hz - 20kHz ± 0.05dB |
| Total harmonics distortion + Noise | 0.0007% |
| Signal/Noise ratio (A-wtd) | 115dB |
| Supported Sample Rates (Optical) | 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz |
| Supported Sample Rates (Coaxial) | 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz |
| Bit depth | 16-bit – 24-bit |
| Pre-amplifier output | |
| Nominal output level | 630mV |
| Output impedance | 230Ω |
| Headphone output | |
| Maximum output level into 600Ω | 5Vrms |
| Output impedance | 1Ω |
| Load range | 16Ω – 2kΩ |
| General | |
| Mains voltage | 110–120V or 220–240V, 50–60Hz |
| Maximum power consumption | 350W |
| Dimensions W x H x D (including feet, control knob and speaker terminals) | 433 x 87 x 310mm |
| Weight (net) | 8.4kg |
| Weight (gross) | 10.7kg |
| Supplied accessories | Mains leads Remote control 2 x AAA batteries |
